CHARACTERISTIC

1. Power System

● The machine adopts double-circuit electronically controlled hydrostatic drive system to ensure good load self-adaptability, loaded and in-situ steering capability, stepless speed regulation, and high flexibility and efficiency and realize outstanding construction performance in narrow sites.

● The transfer case design is added to realize more reasonable arrangement space and higher reliability of traveling hydraulic system.

2.Control system

● Weichai electronic control engine features high intelligence and efficiency and low composite fuel consumption, with the emission compliant with China-III non-road machinery emission regulation.

● The machine is provided with three working power modes at your choice depending on the specific load need under actual working condition to realize the reasonable match among power, efficiency, and power consumption. The unique one-touch boost mode can be used for escape from entrapment under extreme conditions (Such as mud).

3. High performance/Low fuel consumption

● The innovative slip rate control, ECO mode control, steering mode control, reverse gear engine mode, and automatic idling functions are additionally provided to realize the optimal match among power, efficiency, and fuel consumption.

● The 8” full-screen intelligent display and control terminal upgrades the display and control interface, realizes the self-diagnosis malfunction display, clearly indicates the vehicle data information, and features elegant and beautiful appearance.

4. Driving/Riding Environment

●  The integrally stamped hexahedral ergonomic ROPS cab features 4-point MDS shock-absorbing, large space, low vibration, and low noise and can reduce the driver’s parotic noise to 78dB. With excellent airtightness, it can realize 45Pa positive pressure.

●  On the top of full-wraparound upholstery, the A/C air ducts and 8 air vents are installed. The air vents are arranged more reasonably to improve the A/C efficiency. The standard rear-mounted A/C and heating system, cigarette lighter, USB charging port, radio, and sun shade provide more abundant personalized driving/riding experience and guarantee the comfortable and safe driving/riding environment.

5. Large fuel tank for long worktime

●  The chassis system features long ground length, stable driving, and excellent trafficability, with the minimum ground clearance increased to 410mm.

●  The fuel tank capacity is increased to 352L to meet at least 14h operating need.

PARAMETER
