Drive Type:4×2
Kerb Mass(kg):7120
GVW(kg):42000
PRODUCT FEATURE
As the product with great concentriation to develop, the tractor is the most successfully products amonong Chinese truck industry. In terms of technology, we cooperate with international cutting-edge technology, and equip with the most advanced and intelligent manufaturing system, Which lead to higher safety, comfortability, reliability and economy efficiency, the products are standing out in the Chinese high-end logistics market.
PARAMETERS
Item | Unit | Parameter |
Drive Type | - | 4×2 |
Kerb Mass | kg | 7120 |
GVW | kg | 42000 |
Max. Speed | km/h | 90 |
Min. Turning Diameter | m | 12.5 |
Grade Ability | - | ≥25% |
Fuel Tank | L | 400 |
Dimension | mm | 6000×2500×3930 |
Wheelbase | mm | 3600 |
Min. Clearance | mm | 285 |
Approach Angle | - | 18° |
Departure Angle | - | 47° |
Cabin Model | - | G5LH |
Left/Right Driving | - | LHD |
AC | - | Optional |
Person Allowed in | - | 2,3 |
Engine Model | - | WP10.375N |
Emission Standard | - | EUR II |
Displacement | L | 9.726 |
Output Power | KW | 276 |
Max Torque Speed | km/h | 1460 |
Transmission Model | - | 12JSD200TA |
PTO | - | Optional |
Front Axle Model | - | 7.5T |
Rear Axle Model | - | 13T |
Main Reducer Ratio | - | 4.266 |
Rim | - | 22.5×9.00/8.5V-20 |
Tire | - | 315/80R22.5/12.00R20 |
